SKU:40830440
Description:Item type:toolMaterial: metal + plastic Color: Black Input voltage: 12V-48 recommended above 36V Power requirements: less than 12V more than 10A 15V or more than 20A Maximum power: 1800W/2500W Maximum current: 50A Size: 25x12x9cm (Manual measurement, error about 3mm, please understand) Note: The buyer can prepare water cooling system separately, can buy a small water pump and 2 meters of inner diameter Of 4mm rubber hose. 2. You must pay attention to when using switch power supply, because the high-power switching power supply usually have soft start function. 3. When heating the metal objects do not to heat too large metal, otherwise it may be overloaded with power, please add a 35A fuse or ammeter and air switch will be better. (package does not inclues) 4. Although this drive plate can withstand more than 40A current, but it is recommended that not exceed 48V 35A to prevent accidents and damage. 5. Package comes with heating circle diameter is 60 mm, design voltage is 36V, please use separate Power supply voltage regulator module to avoid burn out fan and water pump. 6. The minimum input voltage of the module is 12V, it doesn't mean all the 12V power supply can be used. 7. If you find that the MOS tube fever, then the first thing to consider whether the power output meets the requirements. 8. Do not empty the board, otherwise it will issue a very high frequency of noise, and then MOS tube will burn out. 9. Induction heating is recommended to use 36V 20A power supply 10. Induction heating power is great, so fever is normal, be sure to do a good job of cooling.Packing list:1 x PCB board (with dual fans) 1 x 48V copper tubeNote:The colors deviation might differ due to different monitor settings.
The heating plate is made of military-grade PCB, and the performance is stable.
The power line is fully covered with copper cover design, which can increase the current and heat generation.
Using oversized and large power heat sink to dissipate heat better.
The output terminal uses three M4 copper columns in parallel, which can be connected to other outputs such as high voltage package.
Using six IRFP260 and 12 capacitors in parallel resonance, the power is high and the efficiency is high.
